.XCMG Wheel Excavators Highlights :

  • LIKE Chuan rotating hydraulic transmission, hydraulic brake, turn soft performance, extend service life of rotating equipment.
  • Famous engine, strong power, energy saving.
  • Famous gear pump hydraulic system, cost-effective.
  • hydraulic system configuration overload valve, fill valve, buffer valve, throttle and high pressure filters, extending the service life of hydraulic components.
  • Parker Seal, to ensure the reliability of the hydraulic system; large-capacity radiator, adapt continuous operation.
  • The reliabl frount and rear axle,e, good braking performance and improve driving efficiency.
  • A2F80 motors, sub-action transmission, strong driving force.
  • The main structural parts, strengthen the material, CNC boring and milling machine, to improve the welding process, quality and more reliable service life extension of.
  • Boom cylinder, bucket cylinder rod as a buffer tank, flexible operation, gentle movements, effectively prolong tank life.
  • Streamline operations room, expand the driving vision; can slip the front window to improve ventilation performance.
  • Air seats, premium audio, air conditioning, designing more humane, comfortable operating environment to suit the different environments.
  • Configuration, centralized oil filling equipment, maintenance and more convenient.




MODEL
Engine
Bucket
Operating Weight
XINCAI 498PG / 40kw/2300rpm 0.3 m3 6000 kg
YTR4108G64B / 59kw/2400rpm 0.4 m3 8000 kg
SW100 LR4A3Z-G63D / 83kw/2400rpm 0.5 m3 10000 kg
SW120 YC4A125Z-T11 / 92kw/2400rpm 0.6 m3 12000 kg
SW150 LR6A3Z-G63A / 100kw 2200rpm 0.7 m3 15000 kg
SW220 CUMMINS 6BTAA5.9-C / 133kw/2000rpm 1.0 m3 21750 kg
